Description
FEATURES:
- Advanced Inverter Technology: Provides efficient and stable welding performance with lower power consumption.
- High-Output Capacity: Delivers up to 300A of welding power, suitable for heavy-duty and thick metal welding tasks.
- High-Quality Welds: Capable of producing clean and precise welds on various metals including stainless steel, mild steel, and aluminum.
- Adjustable Settings: Features adjustable current settings to accommodate different welding needs and material thicknesses.
- Portable Design: Despite its high output, it remains relatively lightweight and portable for ease of transport and use in different locations.
- Easy Operation: Simple controls and a user-friendly interface for quick setup and operation.
- High-Frequency Start: Ensures reliable arc starting and improves welding quality.
- Low Maintenance: Designed for minimal maintenance, ensuring long-lasting performance and reliability.
| Input Power | 220 – 240 v + 15% |
| Frequency | 50 – 60 Hz |
| Phase | 1 Ph |
| Rated Input Power (TIG & MMA) | 10.2 / 7.6 kVA |
| Rated Input | 3.5 kVA |
| Rated Duty Cycle | 60 % |
| Current Adjustment Range {TIG & MMA) | 15 ~ 275A / 20~250A |
| Output No-load Voltage | 61 V |
| Down Slope Time | 0~5 S |
| Arc Force Range | 0~ 50 A |
| Efficiency | 85% |
| Post Flow Range | 0.5 ~ 10 s |
| Power Factor | 0.76 |
| Protection Grade | IP 23 |
| Insulation Class | F |
| Ignite Mode | HF |
| Dimension | 480 x 210 x 360 mm |
| Net Weight | 22 Kg |
| Gross Weight | 23 Kg |
| Standard Accessories |
|
| Additional Accessories |
|
